● Test valve type: butterfly valve

● The test medium is water and air

● The equipment integrates mechanical, electrical and hydraulic devices and circulating water system

● The clamping claw of the workbench uses the cylinder to directly drive the clamping butterfly valve to detect, so that the force of each claw is uniform and the clamping is reliable

● The radial movement function of the clamping claw adopts the combination of the cylinder and the rod to realize the radial synchronous movement of each claw and ensure the butterfly valve test of different sizes

● The machine can see whether there is leakage or bubbling in the inner cavity of the butterfly valve, if it is necessary to test the strength of the sealing blind plate.

● There are single-station and two-station types
